Description
Technical Data:
- Series: True Blue T
- Model: True Blue T5
- Mains Plug: Bare Ends
- Lamphead Type: Fresnel, 5,000 W
- Reflector: Spherical specular high purity aluminium
- Lamp Type: 230 V: 5,000 W (CP85); 120 V: 5,000 W (DPY/CP29)
- Power Consumption: 5,000 W
- Voltage Range: 230 V / 120 V
- Lamp Base: G38
- Dimming: yes, 0 to 100 % via external dimming system
- Correlated Color Temperature: 3,200 K
- Beam Angle: 10° to 54°
- Weight in kg net*: approx. 12 kg
- Weight in kg packed*: approx. 17 kg
- Weight in lbs. net*: approx. 26 lbs
- Weight in lbs. Packed*: approx. 37 lbs
- Measurements (HxWxL) incl. Pin in mm*: 655 x 465 x 390 mm
- Measurements (HxWxL) excl. Pin in mm*: 522 x 465 x 390 mm
- Measurements (HxWxL) incl. Pin in inch*: 25,8 x 18,3 x 15,4″
- Measurements (HxWxL) excl. Pin in inch*: 20.6 x 18.3 x 15.4″
- Measurements (HxWxL) Packed size in mm*: 495 x 510 x 555 mm
- Measurements (HxWxL) Packed size in inch*: 12.5 x 20.1 x 21.9″
- Lens / UV-Protection Glass Diameter in mm: 250 mm
- Lens Diameter in inch: 9.8″
- Accessory Diameter in mm: 330 mm
- Accessory Diameter in inch: 13.0″ (Scrim)
- Barndoor in mm: 344 mm
- Barndoor in inch: 13.5″
- Mounting: Spigot 28 mm / 1 1/8″ (1.1″)
- Housing Color: Blue/Silver, Black
- Protection Class / IP Rating: I / IP23
- Certifications: CE, CB, ENEC, cNRTLus
Cellular data:
four sided articular shader
Lamp shielding mesh
filter frame
